1. Architecture Overview

The Platform Calculator is a vanilla-JS ES-module application bundled with Vite. It is split across three source files:

File	Responsibility
`platform-calculator.js`	Data loading, sheet parsing, filter state, matching engine, GPU/NIC slot logic. The single exported entry-point is `initPlatformCalculator()`.
`platform-calculator-htmlbuild.js`	All HTML construction. Exports `renderUI()`, `renderResults()` and `clearFilters()`. Never imports from platform-calculator.js to avoid circular dependencies.
`style.css`	All visual styles for cards, filters, badges, collapsible sections and the summary bar.

Four module-level state variables hold the loaded data:

let _platforms    = [];   // parsed platform objects
let _gpuCatalogue = [];   // GPU catalogue rows
let _cpuCatalogue = [];   // CPU catalogue rows
let _nicCatalogue = [];   // NIC catalogue rows
let _pidToGpu     = {};   // Cisco GPU PID → { model, vramGB, entry }
let _pidToNic     = {};   // Cisco NIC PID → { description, type, ports, … }
let _expCageGpuByChassisId = {}; // GPU slots from type=chnodeexpcage rows, keyed by intoChassisId

2. Data Sources

All data is fetched from Google Sheets via the gviz/tq JSON endpoint. The helper fetchGvizSheet(url) strips the google.visualization.Query.setResponse(…) wrapper, parses the JSON table, and returns { headers, dataRows, fRows } — where fRows carries the formatted (.f) cell string used when the numeric .v value is unreliable (e.g., CPU core counts stored as Excel date serials).

Constant	Sheet (internal name)	Contents
`SHEET_URL`	NVBPTK_PLF	Platform catalogue. One row per server model. Columns cover: identity, CPU config, memory maximums per CPU-qty/gen, drive bay quantities and sizes, PCIe riser slot specs, GPU choices per riser variant, NIC choices per riser variant.
`GPU_SHEET_URL`	NVBPTK_GPU	GPU catalogue. Columns: GPU model, manufacturer, category, VRAM (raw string), interconnect type.
`CPU_SHEET_URL`	NVBPTK_CPU	CPU catalogue. Columns: model number, manufacturer, generation, class, core count (formatted string), clock speeds, TDP, memory type/speed, socket, SPECint score, release date.
`NIC_SHEET_URL`	NVBPTK_NIC	NIC catalogue. Columns: part number (Cisco PID), description, type, port count, speed (Gb), ethernet/IB flags, medium, connector.

3. Initialisation Flow

initPlatformCalculator() is called once from main.js on page load. Its steps:

Injects a loading message into #plat-calc-wrap.
Calls Promise.all([loadPlatforms(), loadGpuCatalogue(), loadCpuCatalogue(), loadNicCatalogue()]) — all four sheets are fetched in parallel.
Calls buildPidToGpuMap() — scans every riser slot in every platform (plus chassis-node Rear Mezz slots, MGPU-server GPU bay slots, and expansion cage slots) for GPU PIDs and their embedded display names, cross-references the GPU catalogue, and populates _pidToGpu.
Calls buildPidToNicMap() — same scan for NIC PIDs, populates _pidToNic.
After all platforms are parsed, parseExpansionCageRows() scans all PLF rows (not just enumerate=Yes) for type=chnodeexpcage rows, reads their ifchassisnode-RearMezz-gpuChoice, and stores the GPU slots keyed by ifnode-intoChassisId. Each chassis-node platform then has its expansionCageGpu array linked by matching intoChassisId.
Calls renderUI(…) to build the filter panel and placeholder.

Riser Group Definitions (`RISER_GROUPS`)

Three PCIe riser groups are defined as a static constant. Each group maps to a set of mutually-exclusive variants (the platform can be ordered with any one variant per riser):

{ id:'r1', label:'Riser 1', requiresCPU2:false,
  variants:[{id:'1A', gpuCol:'ifnode-pcie-riser1-gpuChoice-1A', nicCol:'…-nicChoice-1A'}, …] }
{ id:'r2', label:'Riser 2', requiresCPU2:true,  variants:[…2A, 2B, 2C] }
{ id:'r3', label:'Riser 3', requiresCPU2:true,  variants:[…3A, 3B, 3C, 3D] }

requiresCPU2: true means the riser is physically connected to CPU socket 2 and is only populated when ≥ 2 CPUs are installed. This flag is enforced in all slot-count calculations.

4. Platform Parsing (`parsePlatform`)

Called for every data row in the PLF sheet. Returns null (row is skipped) if enumerate ≠ "Yes". Otherwise builds a rich platform object. Key parsed fields:

Identity & CPU

Object field	Sheet column	Notes
`id`, `name`	`id`, `name`	Display identity
`maxCPUQty`	`ifnode-maxCPUQty`	Hard maximum CPU sockets
`cpuCombinations`	`ifnode-cpuCombinations`	Valid CPU counts, e.g. `"1,2"` → `[1,2]`. Parsed by `parseCpuCombinations()` which splits on whitespace/commas.
`cpuMfg`, `cpuGenA`, `cpuGenB`	`ifnode-cpuMfg`, `ifnode-cpuGenA`, `ifnode-cpuGenB`	Manufacturer and integer generation numbers. `null` when the column is blank or `"na"`.

Memory

Five columns are read, covering all combinations of generation (A / B) and CPU count (1 / 2 / 4). Missing or "na" values are stored as 0.

mem: {
  maxA1: safeF('ifnode-maxMGB-genA-cpux1'),   // Gen A, 1 CPU
  maxA2: safeF('ifnode-maxMGB-genA-cpux2'),   // Gen A, 2 CPUs
  maxA4: safeF('ifnode-maxMGB-genA-cpux4'),   // Gen A, 4 CPUs
  maxB1: safeF('ifnode-maxMGB-genB-cpux1'),   // Gen B, 1 CPU
  maxB2: safeF('ifnode-maxMGB-genB-cpux2'),   // Gen B, 2 CPUs
}

Drives

Nine drive types are defined in DRIVE_DEFS (2.5″ SAS/SATA/NVMe, 3.5″ HDD, NVMe E3.S, etc.). For each type, two columns are read:

Max-qty column — e.g. "[FRONT] 24 [RISER 1B] 2 [RISER 3B] 2". Parsed by both parseDriveQty() (display breakdown) and parsePositionedQty() (per-position array for CPU-filtering).
Size column — e.g. "[FRONT] 960, 1600, … 61400 [FRONTMEZZ] 6400". Parsed by parseSizeGBPerPosition() so each position has its own allowed sizes.

Drives with no valid qty or size data are discarded (.filter(d => d.qty !== null && d.sizes.length > 0)).

GPU & NIC Riser Data

For every RISER_GROUPS variant, two sheet columns are read:

gpuCol → parseGpuChoice() — parses "SLOT1: UCSC-GPU-L4 (NVIDIA L4 (24 GB)) SLOT2: …" into an array of { slotKey, pids, pidNames }. The PID regex is UCS[A-Z]-GPU- so both UCSC-GPU- (rack server) and UCSX-GPU- (chassis node Mezz) PIDs are captured.
nicCol → parseNicChoice() — same format but with NIC PIDs.

Results are stored in p.risers[rgId][variantId] and p.nicRisers[rgId][variantId]. Boolean flags p.hasGpuData and p.hasNicData are set if any slots were found.

Special Platform Types

Three additional platform types require extra column reads beyond the standard riser slots:

type value	Additional columns read	Effect
`chassisnode`	`ifchassisnode-RearMezz-gpuChoice`	Parsed into `p.chassisMezzGpu` (same slot format). These GPUs are counted in `getGpuConfig` as a “Rear Mezz” group, always included (not CPU-count-dependent).
`mgpuserver`	`ifmgpuserver-gpuChoice`, `ifmgpuserver-GPUtoDriveRules`	`mgpuGpuChoice` replaces riser slots entirely (the platform uses dedicated GPU bays). `mgpuDriveRules` is parsed as a `{ gpuQty → maxDrives }` map (e.g. `[2] 24 [4] 16 [8] 8`), used when a drive maxqty cell contains `[ISMGPUSERVER]`.
`chnodeexpcage`	`ifchassisnode-RearMezz-gpuChoice`, `ifnode-intoChassisId`	Scanned by `parseExpansionCageRows()` (not `parsePlatform`). GPU slots are stored in `_expCageGpuByChassisId` and linked to chassis-node platforms via `p.intoChassisId` matching.

GPU Combinations (`ifnode-gpuCombinations`)

When this column is populated (e.g. "2, 4, 8"), the parsed array is stored as p.gpuCombinations. It constrains which GPU quantities are valid for the platform — used during GPU filter matching to ensure only valid configurations are returned.

Drives with `[ISMGPUSERVER]`

If a drive’s maxqty cell contains the literal token [ISMGPUSERVER], the drive is flagged isMgpuVariable: true and its qty is stored as null. At match time, the actual drive limit is read from mgpuDriveRules[chosenGpuQty].

5. Filter UI & `runFilter()`

renderUI() builds the filter panel (left column) and the results placeholder (right column). Every change to a filter input calls runFilter() via change events on selects and Enter keydown on text/number inputs.

runFilter() reads fourteen DOM fields:

DOM id	Variable	Type
`plat-cpu-mfg`	`cpuMfg`	string — CPU manufacturer filter (empty = any). Derived from `ifnode-cpuMfg` in PLF.
`plat-mem`	`memGB`	float — minimum memory in GB
`plat-cpu-gen`	`cpuGen`	float — required CPU generation number (0 = any)
`plat-cpu-qty`	`cpuQty`	int — exact CPU count (0 = any)
`plat-drv-qty`	`drvQty`	int — minimum drive bays
`plat-drv-size`	`drvSize`	float — minimum drive size in GB
`plat-gpu-type`	`gpuPid`	string — Cisco GPU PID (empty = any/none)
`plat-xseries-expansion`	`includeExpansion`	bool — include X-Series GPU Node (UCSX-9508-D expansion cage). Default: on.
`plat-gpu-mem`	`gpuMemGB`	float — minimum total GPU VRAM
`plat-cores`	`coresReq`	int — total cores required across all CPUs
`plat-nic-type`	`nicPid`	string — Cisco NIC PID (empty = any/none)
`plat-nic-qty`	`nicQty`	int — minimum NIC card count
`plat-nic-speed`	`nicSpeed`	float — minimum NIC speed in Gb/s
`plat-nic-ports`	`nicPortQty`	int — minimum total NIC port count

These are bundled into a criteria object. includeExpansion is bound into a gpuFn closure that is passed to renderResults() so all GPU config calls use the same toggle state. A criteria chip "X-Series Expansion excluded" is shown when the toggle is off.

6. Matching Logic (`matchPlatform`)

Each filter check returns { match: false } immediately on failure (short-circuit). The checks run in this order:

Step 1 — CPU Quantity

If cpuQty > 0, the platform's cpuCombinations array is checked. If the array is populated, the selected count must be in the list. If the array is empty (old-format rows), the check falls back to p.maxCPUQty ≥ cpuQty.

Step 2 — CPU Generation

If cpuGen > 0, the platform's cpuGenA and cpuGenB values are compared. If neither matches, the platform fails. Matching gens are collected into activeGens (['A'], ['B'], or ['A','B']). When no gen filter is set, all non-null gens are included.

Step 3 — Memory

The set of CPU counts to check against (effQties) is determined as follows:

If cpuQty > 0: effQties = [cpuQty] — only the selected count is checked.
If no filter: effQties = cpuQtyOptions (all valid counts from cpuCombinations) — the platform's highest available memory wins.

For each combination of activeGens × effQties, the lookup key is p.mem[`max${gen}${qty}`] (e.g. maxA2 for Gen A, 2 CPUs). The global maximum becomes maxMem. If maxMem < memGB the platform is rejected.

Step 4 — Effective CPU Qty for Slots

After the memory check, a single effectiveCpuQty is computed for all subsequent slot-based checks (drives, GPU, NIC):

const maxValidCpu = max(p.cpuCombinations) || p.maxCPUQty;
const effectiveCpuQty = cpuQty > 0 ? cpuQty : maxValidCpu;

This ensures that when no CPU filter is set, the full configuration (all risers populated) is shown.

Step 5 — GPU (runs before drives)

The GPU check is performed before the drive loop so that chosenGpuQty is available for [ISMGPUSERVER] drive limit calculations. Two sub-paths:

With GPU filter (gpuPid set) — calls getGpuConfig(p, gpuPid, effectiveCpuQty, includeExpansion). If p.gpuCombinations is populated, the raw slot count is constrained to valid combinations that fit within the slot maximum. Then the memory requirement (gpuMemGB) is applied. The largest qualifying combination becomes chosenGpuQty and drives the VRAM total. A validCombos array is stored for card display.
Without GPU filter — chosenGpuQty is still resolved from p.gpuCombinations or p.mgpuDriveRules so that isMgpuVariable drives can be sized correctly.

Step 6 — Drives

For each drive type in p.drives, two processing paths exist:

Standard drives (qty not null):

CPU filtering — getRiserMinCpu(posLabel) excludes riser positions needing more CPUs than effectiveCpuQty.
Size filtering — if drvSize > 0, only positions whose sizes include a value ≥ drvSize count towards effectiveQty.
Quantity check — if drvQty > 0 and effectiveQty < drvQty, this drive type is skipped.
Storage totals — maxStorageGB is the sum over available positions of qty × maxSizeForPosition.

MGPU-server variable drives (isMgpuVariable: true, maxqty cell was [ISMGPUSERVER]):

Looks up p.mgpuDriveRules[chosenGpuQty] to determine the maximum bay count for the chosen GPU configuration.
When no GPU filter is set, uses the maximum drive limit across all GPU combinations.
The card shows a per-GPU-configuration drive table (e.g. 2 GPU→ 24 bays, 4 GPU→ 16 bays, 8 GPU→ 8 bays) instead of a fixed bay count.

If any drive filter is active and driveOptions is empty, the platform fails.

Step 7 — CPU Cores

If coresReq > 0, the per-CPU threshold is derived as perCpuCoresReq = ⌈coresReq / effectiveCpuCount⌉. The platform passes if any CPU in getCpusForPlatform() has known cores ≥ threshold or unknown cores (unknown = cannot rule out). Fails only when every catalogued CPU has verified cores below the threshold.

Step 8 — NIC

Activated when any NIC criterion is non-zero. Two sub-paths:

Specific PID — calls getNicConfig(p, nicPid, effectiveCpuQty), checks total count ≥ nicQty and total ports ≥ nicPortQty.
Any NIC — iterates all PIDs present in the platform's NIC risers, filters by speed ≥ nicSpeed, qty and port requirements, selects the PID that maximises total slot count.

A nicResult object is attached to the match on success.

7. GPU & NIC Slot Calculation

`getGpuConfig(p, pid, effectiveCpuQty, includeExpansion)`

Four processing paths, evaluated in priority order:

MGPU-server (p.type === 'mgpuserver') — reads p.mgpuGpuChoice slots directly. Returns immediately without checking risers.
PCIe risers — iterates RISER_GROUPS. Riser groups with requiresCPU2 = true are skipped when effectiveCpuQty < 2. For each eligible group, bestVariantForPid() picks the variant that maximises the slot count.
Chassis-node Rear Mezz (p.chassisMezzGpu) — counted as a fixed additional group, labelled “Rear Mezz”. Always included regardless of CPU count.
X-Series Expansion cage (p.expansionCageGpu) — only included when includeExpansion === true (controlled by the Include X Series GPU Node toggle). Breakdown entries are flagged isExpansion: true and rendered with an amber “via Expansion Node” badge.

Returns:

{ totalCount, totalVramGB, breakdown: [{ label, variantId, count, slotDetails, isExpansion? }] }

`getNicConfig(p, pid, effectiveCpuQty)`

Mirrors getGpuConfig exactly, reading from p.nicRisers instead of p.risers. Returns:

{ totalCount, breakdown: [{ label, variantId, count, slotDetails }] }

`getRiserMinCpu(posLabel)`

Used by the drive-counting logic. Strips any "RISER " prefix, reads the first digit as the riser group number, and returns the requiresCPU2 flag from RISER_GROUPS as a minimum count (1 or 2). Non-riser positions (FRONT, FRONTMEZZ, MIDPLANE) always return 1.

NIC Capability Badges

The NIC Capabilities section renders colour-coded badge rows (port count / speed / type / medium / connector) using buildNicBadges(), matching the visual style of the platform card collapsed-view badges.

8. Rendering Pipeline

`renderResults(results, criteria, …)`

Receives the array of passing match objects. Renders a chip row summarising active criteria, then calls buildCard(r, …) for each result and sets #plat-results innerHTML.

`buildCard(r, criteria, …)`

Each result card is wrapped in a <details class="plat-card-collapse"> element — collapsed by default. The <summary> contains the card header (platform name, ID, badges) plus a compact summary bar showing: Memory max · Best drive configuration · GPU result (if filter active) · NIC result (if filter active). Clicking the header or pressing the toggle arrow (▶/▼) expands the full detail body.

The full card body contains five sections, each built by a dedicated helper:

Section	Built by	Contents
Memory	inline in `buildCard`	Max memory line with Gen/qty annotation. When a memory filter is active, the matched config is highlighted.
Drives	inline in `buildCard`	Per-drive-type rows. Standard drives show bay count, size options, max storage and per-position breakdown. MGPU-server drives show a GPU-config→drive-limit table (e.g. 2 GPU → 24 bays, 4 GPU → 16 bays) instead of a fixed count.
GPU	inline in `buildCard`	When `gpuPid` filter is set: hero count, VRAM total, riser breakdown. When `validCombos` has multiple entries, a blue note shows all valid GPU configurations (e.g. “Valid GPU configurations: 2, 4, 8 × this GPU”). Expansion-node breakdown entries show an amber “via Expansion Node” badge. When no filter: summary table of all available GPU PIDs.
NIC	`buildNicSection()`	Same dual-mode as GPU. Filter-active mode shows hero count, NIC name, speed, port summary. No-filter mode shows all NIC PIDs across all risers with colour-coded attribute badges (port count / speed / type / medium / connector).
CPU Models	`buildCpuSection()` + `<details>`	A per-generation table of supported CPUs with cores, speed, TDP, SPECint. Rows are highlighted green/grey/red based on cores filter. The raw model list is in a nested collapsible.

9. Application Module Map

The toolkit has grown beyond the Platform Calculator. Every tab is a distinct ES module initialised from main.js on page load:

Tab	Module(s)	Entry point	Description
Calculator	`rag-calculator.js`	`initRagCalculator()`	Concurrent user estimator for NVIDIA AI Blueprints. See §10.
GPUs	`gpu-products.js`	`initGpuProducts()`	GPU catalogue browser — renders cards from `GPU_GROUPS`.
Models	`llm-models.js`	`initLlmModels()`	LLM model catalogue browser — renders cards from `LLM_MODEL_GROUPS`.
Platforms	`platform-calculator.js`, `platform-calculator-htmlbuild.js`	`initPlatformCalculator()`	Server platform selector. Fully documented in §1–8 of this page.
Blueprints	`reference-tables.js`, `blueprints.js`	`initReferenceTables()`	Blueprint reference cards with WestconComstor Verified badges. See §11.
BP Components	`bp-components.js`	`initBpComponents()`	NIM component reference — cards from `COMPONENTS` with VRAM / GPU / CPU fields.
Industry / Vertical	`industry-vertical.js`, `blueprints.js`	`initIndustryVertical()`	Industry-tagged blueprint cards with WestconComstor Verified badges. See §11.
BP_Enterprise RAG	`bp-detailed-enterprise-rag.js`	`initBpDetailedEnterpriseRag()`	Deep-dive reference for the Enterprise RAG blueprint architecture.
Deployment	`deployment.js`	`initDeploymentGuide()`	Kubernetes & Helm deployment guide for PoC and scale-out. See §12.

10. RAG Calculator — Concurrent User Estimation Engine

The Calculator tab estimates the maximum concurrent users a given hardware and blueprint configuration can support. It is driven by a single module-level state object and a pure calculate() function in rag-calculator.js.

Calculator State (`state` object)

Field	Default	Description
`gpuId`	`'H100_SXM_80'`	Selected GPU model key — maps to an entry in `GPU_GROUPS`.
`gpuCount`	`1`	Total GPU count for the deployment.
`outputTokens`	`300`	Expected average output tokens per LLM response.
`thinkTime`	`30`	User think time in seconds between requests.
`selectedModelId`	Enterprise RAG default	LLM model ID from `LLM_MODEL_GROUPS`.
`selectedQuantId`	`null`	Quantization override. `null` auto-selects the model's maximum quantization.
`parallelismStrategy`	`'tensor'`	Active multi-GPU parallelism strategy ID (used only when `multiGpuEnabled` is true).
`multiGpuEnabled`	`false`	Multi-GPU strategy toggle state. When `false`, strategy is forced to single-GPU inference. See §10.3.
`blueprintId`	Enterprise RAG	Active NVIDIA AI Blueprint — determines which NIM components are shown.
`components`	required on, optional off	Object mapping component ID → `{ enabled, onGpu }`. Optional components can be toggled off; GPU components can be switched to CPU.

Blueprint & Component Model

Each entry in BLUEPRINTS (blueprints.js) has a required[] and optional[] array of component IDs referencing COMPONENTS in bp-components.js. When a Blueprint is selected the Calculator renders only those components; optional components can be disabled. Blueprints may carry sizingVerified: true (see §11).

The "Show WestconComstor verified only" toggle (#bp-verified-toggle-btn) filters the Blueprint dropdown to entries where sizingVerified === true. Default: off.

Multi-GPU Parallelism Strategy Toggle

A rocker switch (#multi-gpu-toggle-btn) in the Parallelism Strategy row controls whether multi-GPU strategies are enabled. Default: OFF (single GPU inference).

Toggle state	Effective strategy	UI behaviour
OFF (default)	`'request'` (forced internally — hidden from user)	Strategy dropdown hidden. Row shows a "Single GPU Inference" info tooltip explaining the mode and how it compares to each multi-GPU strategy. Row is visually dimmed via `.rag-strategy-row--single`.
ON	`state.parallelismStrategy` (user-selected)	Strategy dropdown visible with all 9 options. Each strategy's tooltip shows a `singleGpuVs` row (vs single GPU) and a `tensorVs` row (vs Tensor Parallelism baseline). A red warning (`.rag-strategy-row--needs-gpu`) appears when the selected strategy requires more GPUs than configured.

Auto-toggle: The GPU count input is wired so that changing from 1 to ≥ 2 automatically enables the multi-GPU toggle, and reducing back to 1 disables it — preventing impossible strategy/count combinations.

Parallelism Strategies (`PARALLELISM_STRATEGIES` constant)

Nine strategies are defined. Each carries a tpsEfficiency multiplier (relative to the Tensor Parallelism baseline at 1.00) and a gpuGrouping describing how the GPU pool is partitioned for calculation:

ID	Label	TPS efficiency	GPU grouping	Primary use case
`tensor`	Tensor Parallelism	1.00 (baseline)	all GPUs = 1 instance	Large model inference (10B+ params) — splits weight tensors across GPUs
`pipeline`	Pipeline Parallelism	0.80	linear layer chain	Very large models — splits transformer layers into pipeline stages
`hybrid`	Hybrid Parallelism	0.90	all GPUs = 1 instance	100B+ production deployments combining TP + PP + DP
`expert`	Expert Parallelism (MoE)	1.20	all GPUs = 1 instance	MoE models — sparse activation means only a fraction of experts fire per token
`sequence`	Sequence / Context Parallelism	0.90	distributed attention	128 K+ token RAG context windows — distributes attention, not weights
`kvcache`	KV Cache Parallelism	0.85	model GPUs + dedicated KV cache GPUs	Production RAG with many concurrent long-context sessions
`request`	Request Parallelism	0.95	independent model replicas	High-throughput serving — near-linear user scaling per GPU group
`data`	Data Parallelism	0.70	gradient-sync replicas	Training / fine-tuning only — not recommended for production inference
`offload`	CPU / GPU Offloading	0.15	CPU-paged weights	VRAM-constrained environments — pages weights via PCIe (5–10× slower)

Calculation Formula (`calculate()`)

Effective strategy: effectiveStratId = state.multiGpuEnabled ? state.parallelismStrategy : 'request'.
GPU instances: determined by gpuGrouping — e.g. 'all' → one instance using all GPUs; 'tp' → gpuCount / minGpusPerInst independent replicas; 'kvcache' → reserves a share of GPUs for KV cache, rest for compute.
TPS per instance: model token-per-second rate at the chosen quantization, scaled by strat.tpsEfficiency.
Response time: responseTimeSec = outputTokens / tpsPerInstance.
QPS: qps = totalTps / outputTokens.
Concurrent users (Little's Law): concurrentUsers = round(qps × (thinkTime + responseTimeSec)).

The result object is returned to the rendering layer which displays a metric card, GPU VRAM allocation bar chart, and strategy breakdown panel.

11. WestconComstor Verified Badge System

Blueprints sized and validated by WestconComstor carry sizingVerified: true in their blueprints.js entry. This flag drives both a Calculator filter toggle and distinct visual treatment on the Blueprints and Industry / Vertical tabs.

Calculator Filter Toggle

The "Show WestconComstor verified only" toggle (#bp-verified-toggle-btn) in the Blueprint Selection row filters the Blueprint dropdown to verified entries only. Default: off. Label text was updated from "Show verified only" to "Show WestconComstor verified only" to make the provenance explicit.

Card Visual Treatment (Blueprints & Industry / Vertical tabs)

Element	CSS class / selector	Visual effect
Card wrapper (Blueprints tab)	`.ref-bp-card--verified`	Gold gradient overlay (`135deg, rgba(217,119,6,0.10) → transparent at 50%`), amber border, `overflow: hidden` to clip the star watermark.
Card wrapper (Industry tab)	`.ind-bp-card--verified`	Same gradient and border treatment as Blueprints tab.
Star watermark (Blueprints)	`.ref-bp-card--verified::before`	90 px ★ pseudo-element in `rgba(217,119,6,0.18)`, anchored top-left. `top: -12px` compensates for font ascender space above the glyph (★ at 90 px has ~14 px of space above the visual character).
Star watermark (Industry)	`.ind-bp-card--verified::before`	72 px ★, `top: -9px` for the smaller size.
Badge row	`.ref-bp-verified-row` / `.ind-bp-verified-row`	`padding-left: 56px / 46px` to clear the star watermark horizontally.
Badge chip	`.ref-badge-verified`	Gold chip: `rgba(217,119,6,0.14)` background, `#92400e` text, amber border, `font-weight: 700`. Text: "★ WestconComstor Verified".

To mark a blueprint as verified, set sizingVerified: true in its blueprints.js entry. Currently only Enterprise RAG (enterprise_rag) is verified.

12. Deployment Guide Tab

The Deployment tab renders a complete Kubernetes & Helm deployment guide, targeting a single-server, 1× GPU proof-of-concept with Qwen3-35B-A3B as the LLM, and extending to a 2-node tensor-parallelism scale-out in Phase 9. All content is rendered in JavaScript by deployment.js → initDeploymentGuide(); there is no server-side component.

Builder Helpers

Function	Returns	Purpose
`phase(num, title, icon, bodyHtml, open?)`	Accordion HTML string	Wraps content in a `.depl-phase` collapsible; open by default for Phases 1–5, closed for 6–9.
`step(n, title, bodyHtml)`	Numbered step HTML	Renders a numbered step block with a circle badge and a titled body.
`cmd(code, lang)`	Dark code block HTML	Wraps a command in `.depl-cmd-block` with language label and a copy-to-clipboard button (wired by `initCopyButtons()`).
`note(text)` / `warn(text)` / `tip(text)`	Callout box HTML	Renders ℹ / ⚠ / ★ callout boxes with the corresponding colour style.

Guide Phases

Phase	Title	Default	Key content
Arch	Architecture Overview	Open	Kubernetes service topology — all 15+ pods with ports (client → ingress → RAG core → NIMs → data layer).
Pre	Prerequisites Checklist	Open	Interactive checkbox list (12 items): NGC API key, hardware, OS, GPU driver, K8s, Helm, StorageClass, GPU Operator, NIM Operator, ECK Operator, NGC CLI. Checks persist in-session.
1	Storage & GPU Operator	Open	Disk audit + PVC size table; optional dedicated data disk mount at `/opt/local-path-provisioner`; local-path StorageClass install; PVC smoke-test; GPU Operator Helm install.
2	Operator Installation	Open	NIM Operator and ECK Operator Helm installs with verification commands.
3	Deploy Helm Chart	Open	`helm upgrade --install` with `poc-values.yaml`; deployment monitoring commands (`watch`, NIMCache status, events).
4	Verify Deployment	Open	Expected `kubectl get pods` output (~15 pods); all services port reference table.
5	Access the Web UI	Open	Port-forward commands for UI (:3000), RAG API (:8081), Ingestor (:8082).
6	Configuration	Closed	GPU time-slicing setup (ConfigMap + ClusterPolicy patch); Qwen3-35B-A3B NIM install (4-step); Milvus VDB switch; NIM cache persistence; optional GPU services table.
7	Lifecycle	Closed	`helm upgrade`; `helm uninstall`; full cleanup (NIMCache + PVC deletion + namespace removal).
8	Troubleshooting	Closed	6-card grid: Pending pods, Init/ContainerCreating, GPU shortage, ErrImagePull, disk exhaustion, port-forward timeouts.
9	Scale-Out — TP=2	Closed	Join 2nd GPU node (`kubeadm join`); GPU Operator auto-config verify; LeaderWorkerSet install; `tp2-values.yaml` overlay (NIM_TENSOR_PARALLEL_SIZE=2, podAntiAffinity); apply + verify multi-node operation; scale reference table (TP=1 → TP=2 → TP=4 → TP=8).

NVIDIA AI Blueprint — Concurrent User Calculator

GPU Reference

LLM Model Reference

Platform Selector

NVIDIA AI Blueprints

Blueprint NIM Components

Industry & Vertical AI Use Cases

NVIDIA Blueprint Toolkit — Technical Reference
